01 / DRAFTSMAN INSTRUMENT · BATCH N° 04

Machined from solid titanium, balanced for seven hours of unbroken thought.

A continuous piston fountain instrument engineered without threads, step-downs or decorative trims. Ground by hand in Kyoto from a single billet of aerospace-grade alloy.

Order Edition N° 01 Read Process

01 BARREL GRADE 5 TITANIUM

02 NIB 14K SOLID GOLD / IRIDIUM

03 FEED JAPANESE EBONITE

04 MASS 28.4 GRAMS POSTED

02 / PRINCIPLE

The case against decoration.

Most writing instruments interrupt the hand with steps, knurling, screw threads and branding bands. Monograph eliminates every transition.

The grip tapers continuously at 1.8 degrees into the nib collar, placing the mass directly over the distal phalanx for zero rotational fatigue.

TOL-01 Continuous profile

Zero threads or step-downs between barrel and grip.

± 0.005 MM

TOL-02 Friction cap seal

Hermetic magnetic air-lock prevents ink drying for 90 days.

0.02 BAR

TOL-03 Acoustic dampening

Internal brass core attenuates high-frequency vibration.

-18 DB

NOMINAL STROKE WIDTH 0.32 MM

FLOW RATE (WATERMAN BLUE) 0.014 ML / MIN

COTTON PAPER FRICTION 0.12 μ DYNAMIC

04 / PROVENANCE

Sourced at origin.

Every component is traceable to the foundry of origin. No synthetic polymers or plated alloys are used anywhere in the assembly.

The raw bar stock is annealed over 18 hours to eliminate internal tension before Swiss turning.

MAT-01 Ti-6Al-4V Grade 5 Titanium

Bar stock forged in Kobe, Japan. Diamond-turned exterior.

950 MPA

MAT-02 14-Karat Solid Gold Nib

Hand-stamped and slit in Kyoto. Hard iridium welding ball.

585 ‰ AU

MAT-03 Natural Vulcanized Ebonite

Natural rubber feed with micro-capillary ink channels.

32 °C CONTACT

MAT-04 Lead-Free Marine Brass

Piston mechanism lead screw machined to 12 micron pitch.

CW614N ALLOY

05 / ENGINEERING SPECIFICATION

Physical measurements.

SPEC-01 Overall length (Capped) 138.0 MM

SPEC-02 Overall length (Uncapped) 126.5 MM

SPEC-03 Barrel diameter 11.2 MM

SPEC-04 Total mass (Uncapped) 19.8 GRAMS

SPEC-05 Total mass (Posted) 28.4 GRAMS

SPEC-06 Reservoir volume 1.40 ML

SPEC-07 Center of mass from tip 52.4 % (PERFECT FULCRUM)

The instrument outlasts the hand that holds it.

Machined in batches of 100 units. Shipped with archival certificate of provenance and custom brass wrench.

Order Batch N° 04 Technical Enquiry
